Page 196 - 《精细化工》2022年第6期

·1262· 精细化工 FINE CHEMICALS
a—样品 C-0；b—样品 C-1；c—样品 C-2；d—样品 C-3；e—样
品 C-4
图 6 整理前后机织羊毛织物残炭的 SEM 图
Fig. 6 SEM images of carbon residue before and after
finishing of woven wool fabrics
3 结论
（1）采用浸轧-焙烘方法，在精仿机织羊毛织物
表面构建了 PA/P(GMA-co-FHBMA)-g-PEGMA/FK
阻燃涂层。与未整理机织羊毛织物相比，PA/P(GMA-
co-FHBMA)-g-PEGMA/FK 整理机织羊毛织物表面
变得粗糙，FTIR 谱图中出现了 β-折叠构象的 C—H、
P—O、C—F 键等特征吸收峰，表明 PA/P(GMA-co-
FHBMA)-g-PEGMA/FK 阻燃涂层成功构建在机织
羊毛织物表面。
（2）PA/P(GMA-co-FHBMA)-g-PEGMA/FK 阻
燃涂层可以明显改善机织羊毛织物阻燃性能，整理
后样品 C-3 的 LOI 可提高至 32.5%±0.2%，损毁长度
为 96 mm，续燃时间降低。阻燃整理后机织羊毛织
物的物理力学性能测试结果表明 ，
PA/P(GMA-co-FHBMA)-g-PEGMA/FK 阻燃整理对
机织羊毛织物断裂强力和手感影响较小。
（3）PA/FK 阻燃整理后机织羊毛织物（C-1）
经过 10 次水洗后，其阻燃性能明显丧失；样品 C-3
在经过 15 次水洗后的 LOI 为 27.3%±0.2%，表明
P(GMA-co-FHBMA)-g-PEGMA 的引入可以提高阻
燃机织羊毛织物阻燃耐久性。
（4）TG 结果表明，PA/P(GMA-co-FHBMA)-g-
PEGMA/FK 阻燃整理会使机织羊毛织物起始热分解
温度降 低， PA/P(GMA-co-FHBMA)-g-PEGMA/FK
可以促进机织羊毛织物形成稳定的炭，在 800 ℃时，
样品 C-3 的残炭量由 C-0 的 0 提高至 12.5%。残炭
的 SEM 测试 表明 ， PA/P(GMA-co-FHBMA)-g-
PEGMA/FK 可在机织羊毛织物表面形成致密性的炭
层，从而提高机织羊毛织物的阻燃性能。
P(GMA-co-FHBMA)-g-PEGMA 和 PA/FK 可以
增强机织羊毛织物的阻燃耐久性能。本课题组将进
一步改进 PA/FK 的结合方式，制备系列生物质阻燃
剂，以期在得到更好阻燃效果和耐久性的同时，减
少阻燃剂对机织羊毛织物白度的降低。
参考文献：
[1] XUE R J (薛日杰), WANG S G (王树根), SHI M W (施楣梧).
第 39 卷
Application of TiO 2-SnO 2 composite sol for wool flame retardant
finishing[J]. Journal of Textile Research (纺织学报), 2017, 38(12):
95-100.
[2] PAN J (潘健). Application of silicon phosphorus hybrid flame
retardant in finishing wool carpet[D]. Urumqi: Xinjiang University
(新疆大学), 2020.
[3] DING J, LAI R H, CHEN W J, et al. Environmentally friendly
biological nanofibers based on waste feather keratin by
electrospinning with citric acid vapor modification[J]. Journal of
Applied Polymer Science, 2020, 138(18): 50348.
[4] YU W F (于婉菲). Salt alginate/carboxymethyl cellulose preparation
and properties of flame retardant alpaca fabric[D]. Harbin: Northeast
Forestry University (东北林业大学), 2017.
[5] YU K X (于凯旋), GUO L J (郭利静), SHI X L (石旭柳), et al.
Application progress of bio-based flame retardants[J]. Plastics (塑
料), 2021, 50(3): 99-105, 120.
[6] CHENG X W, TANG R C, YAO F, et al. Flame retardant coating of
wool fabric with phytic acid/polyethyleneimine polyelectrolyte
complex[J]. Progress in Organic Coatings, 2019, 132: 336-342.
[7] ZHOU Z, BAO W R, DI Y B, et al. Preparation and characterization
of cyclotriphosphazenekeratin/viscose fibers[J]. Fibers and Polymers,
2015, 16(3): 560-564.
[8] GUO L X (郭路星). Synthesis of feather protein based inflating
flame retardant and its applicating to cotton fabric[D]. Xi'an: Xi'an
Polytechnic University (西安理工大学), 2011.
[9] WU N J (吴宁晶), MA X B (马小兵), DING J H (于基航), et al.
Research progress on flame retardants modification and charring of
biomaterials[J]. Journal of Qingdao University of Science and
Technology (Natural Science Edition) (青岛科技大学学报: 自然科
学版), 2021, 42(2): 85-89.
[10] CHILAKAMARRY C R, MAHMOO S, SAFFE S N B M, et al.
Extraction and application of keratin from natural resources: A
review[J]. 3 Biotech, 2021, 11(5): 1-12.
[11] ZHENG H L, LIU X H, FANG Y C, et al. Construction of the
photonic crystal structural colors with high colorfastness using the
novel synthesis adhesive[J]. IOP Conference Series: Materials
Science and Engineering, 2019, 585(1): 012048.
[12] WANG X Y, LU C Q, CHEN C X. Effect of chicken-feather
protein-based flame retardant on flame retarding performance of
cotton fabric[J]. Journal of Applied Polymer Science, 2014, 131(15):
40584.
[13] CHENG X W, GUAN J P, YANG X H, et al. Durable flame
retardant wool fabric treated by phytic acid and TiO 2 using an
exhaustion-assisted pad-dry-cure process[J]. Thermochimica Acta,
2018, 665(9): 28-36.
[14] YANG P X (杨佩鑫), MA X P (马晓谱), WU H G (吴汉光), et al.
Research progress in the application of phytic acid and phytic acid
salt in blend flame retardant modification for polymers[J]. Journal of
Beijing Institute of Fashion Technology (Natural Science Edition)
(北京服装学院学报: 自然科学版), 2020, 40(3): 88-95.
[15] YANG H W (杨海伟), WANG Z Q (王宗乾), LI C L (李长龙).
Effect of phytic acid on the properties of feather keratin finished
polyester fabric[J]. Fine Chemicals ( 精细化 工 ), 2021, 38(3):
613-618, 639.
[16] ZHANG J (张继), BIAN J C (边金彩), HE Z N (何珍妮), et al.
Synthesis and application of oligohydroxypropyl ethyl phosphate
flame retardant[J]. Fine Chemicals ( 精细 化工 ), 2021, 38(9):
1913-1919, 1927.
[17] WANG X Y, LU C Q, CHEN C X. Effect of chicken-feather
protein-based flame retardant on flame retarding performance of
cotton fabric[J]. Journal of Applied Polymer Science, 2014, 131(15):
40584.
[18] MATHUR P, SHEIKH J N, SEN K. Durable flame- retardant wool
using sulphamic acid[J]. Polymer Degradation and Stability, 2020,
174(C): 109101.
（下转第 1289 页）
