第 1 期 韩 旭，等: 纳米 TiO 2 增强阴离子导电膜中碱性离子液体稳定性
碱时间的增加而逐渐减弱，说明季铵基团在泡碱过
程中不断发生降解。
2.8 离子液体流失率测定
高湿环境下，PVA 骨架由于膜的溶胀会变得松
散，[DMPy][OH]碱性离子液体会从 PVA 骨架中流
失，导致膜性能下降。因此，有必要对复合膜中离
子液体流失情况进行考察。本文将复合膜在室温下
完全浸泡于去离子水中，测定浸泡前后复合膜的
IEC 值，计算膜中离子液体流失率，结果见图 10。
图 10 P-X 和 PT-X 复合膜的离子液体流失率
Fig. 10 [DMPy][OH] loss rate of P-X and PT-X composite
membranes
由图 10 可知，离子液体流失率随着膜内离子液
体含量的增加而逐渐增大，这是因为膜内空间体系
能稳定存在的离子液体数量是有限的，离子液体数
量超过临界值，多余的部分就会以游离的状态存在
于膜中，极易流失。而添加 Nano-TiO 2 后，复合膜
中离子液体流失率大幅降低，这是因为处于游离态
的离子液体在自组装作用下被吸附到 Nano-TiO 2 表
面，形成复合颗粒，而 Nano-TiO 2 中 Ti—O 的强极性
可以使吸附的水分子发生解离生成钛羟基
基又可以与 PVA 中的羟基形成氢键，使其被固载到
PVA 骨架上，从而使离子液体较稳定地存在于膜结
构中。其中，PT-25 由于 Nano-TiO 2 的添加，复合膜
的离子液体流失率降幅约 34.3%，表明 Nano-TiO 2 的
添加对离子液体的流失有一定的抑制作用。
3 结论
通过共混-流延法制备 PVA-[DMPy][OH]-TiO 2
复合膜，借助 GA 的化学交联作用使复合膜具备半
互穿的网状结构。该系列复合膜具有制备工艺简单、
环境友好等特点，同时具有较高的电导率，良好的机
械性能，优异的热稳定性、耐碱稳定性。结果表明，
当[DMPy][OH]质量分数为 25%时，PT-25 在 80 ℃的
3
电导率为 2.78×10 S/cm；在室温下 3 mol/L KOH 中
进行加速老化实验，120 h 后，电导率无明显变化，
表现出优异的耐碱稳定性；热分解温度高于 200 ℃；
·135·
室温浸泡于水中 12 h 后，离子液体流失率也仅为
23.2%。PVA-[DMPy][OH]-TiO 2 复合膜具备在燃料电
池中应用的潜力。
参考文献：
[1] Chen Lihao (陈力豪), Wang Lulu (王璐璐), Wang Jilin (王吉林), et
al. Synthesis of dual-core basic ionic liquids and its application for
anion exchange membranes[J]. Chemical Industry and Engineering
Progress (化工进展), 2016, 35 (4) : 1154-1161.
[2] Zhu X, Wang B, Wang H. Effects of [Bmim]OH on structure and
conductive properties of alkaline PVA/[Bmim]OH membranes[J].
Polymer Bulletin, 2010, 65(7): 719-730.
[3] Yi S, Zhang F, Wei L, et al. Anhydrous elevated-temperature polymer
electrolyte membranes based on ionic liquids[J]. Journal of
Membrane Science, 2011, 366(1): 349-355.
[4] Che Q, Zhou L, Wang J. Fabrication and characterization of
phosphoric acid doped imidazolium ionic liquid polymer composite
membranes[J]. Journal of Molecular Liquids, 2015, 206: 10-18.
[5] Chu F, Lin B, Yan F, et al. Macromolecular protic ionic liquid-based
proton-conducting membranes for anhydrous proton exchange
membrane application[J]. Journal of Power Sources, 2011, 196(19):
7979-7984.
[6] Wang S, Cao Z, Li S, et al. A molecular dynamics simulation of the
structure of ionic liquid ([BMIM][PF 6])/rutile (110) interface[J].
Scientia Sinica: Chimica (中国科学: 化学), 2009, 52(9): 1434-1437.
[7] Meng H, Chen X W, Wang J H. One-pot synthesis of N, N-bis[2
-methylbutyl] imidazolium hexafluorophosphate–TiO 2 nanocomposites
and application for protein isolation[J]. Journal of Materials Chemistry,
2011, 21(38): 14857-14863
[8] Chang H C, Chang S C, Hung T C, et al. A high-pressure study of the
effects of TiO 2 nanoparticles on the structural organization of ionic
liquids[J]. Chromosome Research An International Journal on the
Molecular Supramolecular and Evolutionary Aspects of Chromosome
Biology, 2011, 10(7): 571-577.
[9] Zhang Min (张敏), Yang Yu (杨鱼), Li Chengtao (李成涛), et al.
Preparation and properties of fast water absorption PVA /HEC porous
composites [J]. Fine Chemicals (精细化工), 2017, 34(5): 505-512.
[10] Macfarlane D R, Forsyth S A, Golding J, et al. Ionic liquids based on
imidazolium, ammonium and pyrrolidinium salts of the dicyanamide
anion[J]. Green Chemistry, 2002, 4(5): 444-448.
[11] Chu Y, Chen Y, Chen N, et al. A new method for improving the ion
conductivity of anion exchange membranes by using TiO 2
nanoparticles coated with Ionic liquid[J]. Rsc Advances, 2016, 6(99):
96768-96777.
[12] Liu He (柳鹤), Wang Suli (王素力), Jiang Luhua (姜鲁华), et al. The
stability of poly (tetrafluoroethylene-co-perfluoropropyl vinyl ether)
based anion exchange membranes used for alkaline fuel cell[J].
Scientia Sinica: Chimica (中国科学: 化学), 2011, 41(12): 1857-1863.
[20] ，钛羟 [13] Fu J, Lin R, Lv H, et al. Preparation and properties of poly(vinyl
alcohol)/poly(vinyl pyrrolidone) composites for solid alkaline
electrolyte membranes[J]. Acta Physico-Chimica Sinica, 2010,
26(10): 2653-2658.
[14] Qiao J, Takeo Hamaya A, Okada T. Chemically modified poly(vinyl
alcohol)−poly(2-acrylamido-2- methyl-1-propanesulfonic acid) as a
novel proton-conducting fuel cell membrane[J]. Chemistry of
Materials, 2005, 17(9): 2413-2421.
[15] Tang D P, Pan J, Lu S F, et al. Alkaline polymer electrolyte fuel cells:
Principle, challenges, and recent progress[J]. Scientia Sinica:
Chimica (中国科学: 化学), 2010, 53(2): 357-364.
[16] Wang Y, Wan H, Wang J, et al. Hydroxide ion highway constructed
by orderly aligned quaternary ammonium groups in anion exchange
membranes[J]. Journal of the Electrochemical Society, 2017,
164(12): F1051-F1062.
[17] Kan C W, Au C H. Effect of biopolishing and UV absorber treatment
on the UV protection properties of cotton knitted fabrics[J].
Carbohydrate Polymers, 2014, 101(1): 451-456.
[18] Li Tuanle (李团乐), Pei Hongchang (裴洪昌), Yuan Weijin (袁威津),
et al. Preparation and characterization of polyvinyl alcohol
copolymer grafted with 4'-formoxylbenzo-15-crown-5-ether for
Lithium isotopes separation[J]. Acta Polymerica Sinica (高分子学
报), 2015, (7): 792-799.
[19] Zhu Zipei (朱子沛), Tang Xu (汤旭), He Qi (何其). Preparation and
performance of modified Al 2O 3/PVDF hybrid membrane[J]. Fine
Chemicals (精细化工), 2016, 33 (11): 1201-1206, 1211.
[20] Sun Fengyu (孙奉玉), Wu Ming (吴鸣). Relationship between
optical surface properties and photo catalytic activity of titanium
dioxide [J]. Chinese Journal of Catalysis (催化学报), 1998, 19(2):
121-124.
